B6030 VERTICAL BALER

B6030 Vertical Baler

The B6030 Vertical Baler from Bramidan is the industry leading mill-size large baler. With a press force of 66,200 lbs., retainer dogs to keep material compressed, and a frontal tie system, this machine is the perfect solution to your waste handling needs. This model operates on three phase power supply and is available in both 480V and 600V units.

This machine offers the lowest in-class noise levels and is incredibly simple to use. It’s simple and safe operation comes standard with an automatic full light indicator and two-handed automatic bale eject. The B6030 comes standard with the BRA-IN monitoring system from Bramidan that tracks bale output, sends notifications when bales are ready to be tied off, and more! Take your waste management practices to the next level with this simple, small, and powerful unit!

  • Extra wide chamber (>60 inches)
  • Compacts large bulky materials
  • Available with Sliding Door Option for reduced footprint.
  • Tie off finished bales with metal wire or polyblend strapping
  • Lowest noise level in the market (<62 dB)
  • Full bale light notification
  • Automatic ejection of finished baler
woman loading cardboard into a teal baler
Click to Enlarge Images

Press Force

66,200 lbs.

Waste Volume

Large

Feed Opening Size

WxH (in.) 60″ x 24″

Bale Size

WxDxH (in.) 60″x 30″x 48″

Bale Weight

800 – 1,300 lbs.

Waste Types

Cardboard, Paper, Plastic

Press Force

66,200 lbs.

Waste Volume

Large

Feed Opening Size

WxH (in.) 60″ x 24″

Bale Size

WxDxH (in.) 60″x 30″x 48″

Bale Weight

800 – 1,300 lbs.

Waste Types

Cardboard, Paper, Plastic

Product Features

Heavy Bale Weight

Compact cardboard, paper and soft plastic into 1,000 pound mill-size bales with the large 60 inch chamber.

Financing Available

Kernic Systems offers financing rates through a preferred third-party lender. Take your recycling and waste management processes to the next level, all for one low monthly fee.

Product Highlights

  • Available in 3-phase 480V and 600V units.

  • ANSI Z245.5, UL and CSA Compliant
  • Safe to Operate – complies with all Ontario and Canadian safety standards
  • Frontal Tie System – allows baler to be placed up against a wall.

Connect, monitor and analyze your equipment

With the BRA-IN monitoring solution you can make faster and better decisions while reducing your costs of operation.

  • Automated pick-ups and alerts possible
  • Online access to live status of your equipment
  • Output documentation possible

Technical Specifications

noise level comparison of b6030 vertical baler and other noises
b6030 technical specs
208/220/480V also available.
b6030 dimensions
